Caractéristiques:

• Ambient Temperature: -20C~+50Celsius
• Angle d'Etape (degrés): 1.8
• Application: cnc Industrial Machinery
• Certification: ce
• Certification: ISO
• Certification: ROHS
• Couple de Possession: 3N.m (417oz-in)
• Courant/ Phase: 4.2A
• Dielectric Strength: 500VAC/1 minute
• Frame size: NEMA 23, 57mm
• Lead wire No.: 4 lead
• Length of body: 112mm
• Numéro de Modèle: Stepper Motor 57HS11242B4
• Origine: CN (Origine)
• Phase: 2
• Resistance Accuracy: ±10%
• Shaft diameter: 8mm
• Step Angle Accuracy: ±5%
• Structure: nema23 dual shaft stepper motor
• Type: HYBRID
